The Certificates Group
The following tables contain the OIDs and the corresponding name for the certificates group. The table lists the valid
actions for the OIDs and the descriptions. The request type GET implies the support of the GETNEXT
request.
Some SNMP queries are only available starting from anynode version 4.14.
Name: certificateNumber
OID: .1.3.6.1.4.1.42303.2.5.1.0
Request Type: GET
Description: Contains the amount of entries in the following certificate table.
Name: certificateTable
OID: .1.3.6.1.4.1.42303.2.5.2
Request Type: GET
Description: The table with certificate information.
Name: certificateEntry
OID: .1.3.6.1.4.1.42303.2.5.2.1
Request Type: GET
Description: The definition of the information for one certificate. The following OIDs in this table are available for each certificate. The index at the end of the OID selects the certificate entry.
Name: certficateIndex
OID: .1.3.6.1.4.1.42303.2.5.2.1.1
Request Type: GET
Description: A unique value for each certificate. Its value ranges between 1 and the value of certificateNumber.
Name: certificateVersion
OID: .1.3.6.1.4.1.42303.2.5.2.1.2
Request Type: GET
Description: The version number of the certificate as an integer value.
Name: certificateSerialNumber
OID: .1.3.6.1.4.1.42303.2.5.2.1.3
Request Type: GET
Description: The serial number of the certificate. The data type is DisplayString.
Name: certificateName
OID: .1.3.6.1.4.1.42303.2.5.2.1.4
Request Type: GET
Description: The name of the certificate. The data type is DisplayString, and the
contents depend on the issuer.
Name: certificateExpiresInDays
OID: .1.3.6.1.4.1.42303.2.5.2.1.5
Request Type: GET
Description: The amount of days when the certificate will expire, zero if the certificate is expired.
Name: certificateActive
OID: .1.3.6.1.4.1.42303.2.5.2.1.6
Request Type: GET
Description: Shows if the certificate is active. The data type is integer, with possible values:
1: Yes
2: No
Name: certificateExpired
OID: .1.3.6.1.4.1.42303.2.5.2.1.7
Request Type: GET
Description: Shows if the certificate is expired. The data type is integer, with possible values:
1: Yes
2: No
Name: certficateValidFrom
OID: .1.3.6.1.4.1.42303.2.5.2.1.8
Request Type: GET
Description: The UTC date when the certificate becomes active. The format is an eight-byte octet string in the short DateAndTime format.
Name: certificateValidUntil
OID: .1.3.6.1.4.1.42303.2.5.2.1.9
Request Type: GET
Description: The UTC date when the certificate will expire. The format is an eight-byte octet string in the short DateAndTime format.
Name: certificateIssuerCountry
OID: .1.3.6.1.4.1.42303.2.5.2.1.10
Request Type: GET
Description: The country code set by the issuer of the certificate, e.g., DE. The data type
is DisplayString.
Name: certificateIssuerCommonName
OID: .1.3.6.1.4.1.42303.2.5.2.1.11
Request Type: GET
Description: The common name set by the issuer. This could be a symbolic name or a domain name.
The data type is DisplayString.
Name: certificateIssuerState
OID: .1.3.6.1.4.1.42303.2.5.2.1.12
Request Type: GET
Description: The state set by the issuer, e.g., Washington. The data type is DisplayString.
Name: certificateIssuerLocality
OID: .1.3.6.1.4.1.42303.2.4.2.1.13
Request Type: GET
Description: The locality set by the issuer. This may be the city, e.g., Redmond. The data type
is DisplayString.
Name: certificateIssuerOrganization
OID: .1.3.6.1.4.1.42303.2.4.2.1.14
Request Type: GET
Description: The organization set by the issuer. The data type is DisplayString.
Name: certificateIssuerOrganizationUnit
OID: .1.3.6.1.4.1.42303.2.4.2.1.15
Request Type: GET
Description: The organization unit set by the issuer, e.g., Marketing. The data type is DisplayString.
Name: certificateSubjectCountry
OID: .1.3.6.1.4.1.42303.2.5.2.1.16
Request Type: GET
Description: The country code from the subject of the certificate, e.g., DE. The data type is
DisplayString.
Name: certificateSubjectCommonName
OID: .1.3.6.1.4.1.42303.2.5.2.1.17
Request Type: GET
Description: The common name from the subject of the certificate. This could be a symbolic name
or a domain name. The data type is DisplayString.
Name: certificateSubjectState
OID: .1.3.6.1.4.1.42303.2.5.2.1.18
Request Type: GET
Description: The state from the subject of the certificate, e.g., Washington. The data type
is DisplayString.
Name: certificateSubjectLocality
OID: .1.3.6.1.4.1.42303.2.5.2.1.19
Request Type: GET
Description: The locality from the subject of the certificate. This may be the city, e.g., Redmond.
The data type is DisplayString.
Name: certificateSubjectOrganization
OID: .1.3.6.1.4.1.42303.2.5.2.1.20
Request Type: GET
Description: The organization from the subject of the certificate. The data type is DisplayString.
Name: certificateSubjectOrganizationUnit
OID: .1.3.6.1.4.1.42303.2.5.2.1.21
Request Type: GET
Description: The organization unit from the subject of the certificate, e.g., Marketing. The
data type is DisplayString.
