This chapter outlines the OIDs and corresponding names for the configuration group in anynode.

The Configuration Group

The following tables contain the OIDs and the corresponding name for the configuration group. The table lists the valid actions for the OIDs and the descriptions. The request type GET implies the support of the GETNEXT request.

Some SNMP queries are only available starting from anynode version 4.14.

Name: cfgLicenseExpiresWarning

OID: .1.3.6.1.4.1.42303.2.6.1.0

Request Type: GET/SET

Description: Specifies the number of days to start sending the licenseExpiresWarning trap before a license will expire. The value zero specifies that no trap will be sent.

Name: cfgLicenseExpiresCritical

OID: .1.3.6.1.4.1.42303.2.6.2.0

Request Type: GET/SET

Description: Specifies the number of days to start sending the licenseExpiresCritical trap before a license will expire. The value zero specifies that no trap will be sent.

Name: cfgLicenseRepeatWarnings

OID: .1.3.6.1.4.1.42303.2.6.3.0

Request Type: GET/SET

Description: Specifies the number of days after a license warning is repeated. The value zero specifies that the warning is not repeated.

Name: cfgCertificateExpiresWarning

OID: .1.3.6.1.4.1.42303.2.6.4.0

Request Type: GET/SET

Description: Specifies the number of days to start sending the certificateExpiresWarning trap before a certificate will expire. The value zero specifies that no trap will be sent.

Name: cfgCertificateExpiresCritical

OID: .1.3.6.1.4.1.42303.2.6.5.0

Request Type: GET/SET

Description: Specifies the number of days to start sending the certificateExpiresCritical trap before a certificate will expire. The value zero specifies that no trap will be sent.

Name: cfgCertificateRepeatWarnings

OID: .1.3.6.1.4.1.42303.2.6.6.0

Request Type: GET/SET

Description: Specifies the number of days after a certificate warning is repeated. The value zero specifies that the warning is not repeated.

Name: cfgWarnCallNoLicense

OID: .1.3.6.1.4.1.42303.2.6.7.0

Request Type: GET/SET

Description: The parameter specifies if traps should be sent when a call could not be served because no more licenses are available. The data type is integer, with the following options:

  • 1 disable

  • 2 enable

Name: cfgWarnCallNoRoute

OID: .1.3.6.1.4.1.42303.2.6.8.0

Request Type: GET/SET

Description: The parameter specifies if traps should be sent when an incoming call could not be served because no route could be assigned. The data type is integer, with the following options:

  • 1 disable

  • 2 enable

Name: cfgCallHistoryMaxSessions

OID: .1.3.6.1.4.1.42303.2.6.9.0

Request Type: GET/SET

Description: The parameter specifies the maximum amount of sessions that should be stored in the call history database. The minimum value is 10,000, the default value is 500,000. The value zero sets the call history to unlimited.

Name: cfgCallHistoryCleanupInterval

OID: .1.3.6.1.4.1.42303.2.6.10.0

Request Type: GET/SET

Description: The parameter specifies the interval for checking if the number of sessions in the call history exceeds the configured maximum. The value is given in minutes, with a minimum of 1. The default value is set to 1440 (once a day).

Name: cfgCallHistoryEnabled

OID: .1.3.6.1.4.1.42303.2.6.11.0

Request Type: GET/SET

Description: The parameter specifies if session information should be written to the call history. The data type is integer; the following options are available:

  • 1 disable

  • 2 enable

Name: cfgCallHistoryCleanupEnabled

OID: .1.3.6.1.4.1.42303.2.6.12.0

Request Type: GET/SET

Description: The parameter specifies if a call history cleanup should be done. The data type is integer; the following options are available:

  • 1 disable

  • 2 enable

Name: cfgCallHistoryMaxRetentionTime

OID: .1.3.6.1.4.1.42303.2.6.13.0

Request Type: GET/SET

Description: Integer value that specifies after how many days call history records should be deleted. If the value is not set, this option is disabled. The set value is independent of the other delete options. The condition that is first met determines the time of deletion.

Name: cfgCallHistoryMaxRetentionTimeRecordings

OID: .1.3.6.1.4.1.42303.2.6.14.0

Request Type: GET/SET

Description: The value that specifies after how many days recorded files should be deleted. If the value is not set, this option is disabled. The set value is independent of the other delete options. The condition that is first met determines the time of deletion.

Name: cfgDiskSpaceWarning

OID: .1.3.6.1.4.1.42303.2.6.15.0

Request Type: GET/SET

Description: Specifies the minimum space in megabytes to start sending the diskSpaceWarning trap.

Name: cfgDiskSpaceCritical

OID: .1.3.6.1.4.1.42303.2.6.16.0

Request Type: GET/SET

Description: Specifies the minimum space in megabytes to start sending the diskSpaceCritical trap.

Name: cfgDiskSpaceRepeatWarnings

OID: .1.3.6.1.4.1.42303.2.6.17.0

Request Type: GET/SET

Description: Specifies the number of days after a disk space warning is repeated. The value zero specifies that the warning is not repeated.

Name: cfgSipFlowRecordingEnabled

OID: .1.3.6.1.4.1.42303.2.6.18.0

Request Type: GET/SET

Description: The parameter specifies if the recording of signaling messages to a database should be done. The data type is integer; the following options are available:

  • 1 disable

  • 2 enable

Name: cfgSipFlowMaxMessageLenth

OID: .1.3.6.1.4.1.42303.2.6.19.0

Request Type: GET/SET

Description: Specifies the max size of a SIP flow message in bytes. If a message is longer, it will be truncated. If the value is set to zero, this option is disabled.

Name: cfgSipFlowMaxRetentionTime

OID: .1.3.6.1.4.1.42303.2.6.20.0

Request Type: GET/SET

Description: The value that specifies after how many days recorded SIP flows should be deleted. If the value is set to zero, this option is disabled.
