The Licenses Group
The following tables contain the OIDs and the corresponding names for the licenses group. The table lists the valid actions
for the OIDs and the descriptions. The request type GET implies the support of the GETNEXT request.
Some SNMP queries are only available starting from anynode version 4.14.
Name: licenseNumber
OID: .1.3.6.1.4.1.42303.2.4.1.0
Request Type: GET
Description: Contains the amount of entries in the following license table.
Name: licenseTable
OID: .1.3.6.1.4.1.42303.2.4.2
Request Type: GET
Description: The table with license information.
Name: licenseEntry
OID: .1.3.6.1.4.1.42303.2.4.2.1
Request Type: GET
Description: The definition of the information for one license. The following OIDs in this table are available for each license. The at the end of the OID selects the license entry.
Name: licenseIndex
OID: .1.3.6.1.4.1.42303.2.4.2.1.1
Request Type: GET
Description: A unique value for each license. Its value ranges between 1 and the value of licenseNumber.
Name: licenseDescription
OID: .1.3.6.1.4.1.42303.2.4.2.1.2
Request Type: GET
Description: The symbolic description of the license, e.g., TE-SYSTEMS GmbH - 2 sessions - 365
days trial. The data type is DisplayString.
Name: licenseIdentifier
OID: .1.3.6.1.4.1.42303.2.4.2.1.3
Request Type: GET
Description: The unique identifier of the license. The data type is DisplayString.
Name: licenseStatus
OID: .1.3.6.1.4.1.42303.2.4.2.1.4
Request Type: GET
Description: The state of the license, e.g., is the system using this license or not. The data type is integer. The following options are available:
1: Inactive (configured but not activated)
2: Active
3: Expired
4: Invalid
5: Invalid signature
6: Invalid hardware ID
7: Invalid product
8: SUS Expired
9: Already active (used by another process)
10: Not yet active
Name: licenseExpiresInDays
OID: .1.3.6.1.4.1.42303.2.4.2.1.5
Request Type: GET
Description: If the license is time-limited (licenseValidUntil contains a valid date), this indicates the amount of days until the license will expire or zero if the license is expired. If the license is not time-limited, the value is always zero.
Name: licenseValidFrom
OID: .1.3.6.1.4.1.42303.2.4.2.1.6
Request Type: GET
Description: The UTC date and time when the license becomes active. The format is an eight-byte octet string in the short DateAndTime format.
Name: licenseValidUntil
OID: .1.3.6.1.4.1.42303.2.4.2.1.7
Request Type: GET
Description: The UTC date and time when the license will expire. The format is an eight-byte octet string in the short DateAndTime format. If the license is not limited, all octets are set to zero.
Name: licenseSUSExpiresInDays
OID: .1.3.6.1.4.1.42303.2.4.2.1.8
Request Type: GET
Description: The amount of days when the software upgrade service will end.
Name: licenseSUSUntil
OID: .1.3.6.1.4.1.42303.2.4.2.1.9
Request Type: GET
Description: The UTC date as a readable string when the software upgrade service will end. The format is an eight-byte octet string in the short DateAndTime format.
Name: licenseTelSessions
OID: .1.3.6.1.4.1.42303.2.4.2.1.10
Request Type: GET
Description: The amount of tel-sessions granted by this license entry.
Name: licenseG722Decoder
OID: .1.3.6.1.4.1.42303.2.4.2.1.11
Request Type: GET
Description: The amount of G.722 decoder instances granted by this license entry.
Name: licenseG722Encoder
OID: .1.3.6.1.4.1.42303.2.4.2.1.12
Request Type: GET
Description: The amount of G.722 encoder instances granted by this license entry.
Name: licenseG729Decoder
OID: .1.3.6.1.4.1.42303.2.4.2.1.13
Request Type: GET
Description: The amount of G.729 decoder instances granted by this license entry.
Name: licenseG729Encoder
OID: .1.3.6.1.4.1.42303.2.4.2.1.14
Request Type: GET
Description: The amount of G.729 encoder instances granted by this license entry.
Name: licenseOpusDecoder
OID: .1.3.6.1.4.1.42303.2.4.2.1.15
Request Type: GET
Description: The amount of OPUS decoder instances granted by this license entry.
Name: licenseOpusEncoder
OID: .1.3.6.1.4.1.42303.2.4.2.1.16
Request Type: GET
Description: The amount of OPUS encoder instances granted by this license entry.
Name: licenseDemo
OID: .1.3.6.1.4.1.42303.2.4.2.1.17
Request Type: GET
Description: The information if the license has demo constraints. Values are:
1: Yes
2: No
Name: licenseAbo
OID: .1.3.6.1.4.1.42303.2.4.2.1.18
Request Type: GET
Description: The information if the license uses the subscription mode, which requires that the license is validated by the auto updater. Values are:
1: Yes
2: No
Name: licenseAutoUpdaterFailed
OID: .1.3.6.1.4.1.42303.2.4.2.1.19
Request Type: GET
Description: The UTC date as a readable string when the auto updater failed the last time to validate the license. If no failure occurred, the value is zero. The format is an eight-byte octet string in the short DateAndTime format.
Name: licenseRecordingSessions
OID: .1.3.6.1.4.1.42303.2.4.2.1.20
Request Type: GET
Description: The amount of Recording sessions licensed by this license entry.
Name: licenseTelTeamsSiteSessions
OID: .1.3.6.1.4.1.42303.2.4.2.1.21
Request Type: GET
Description: The amount of Tel Teams Site Sessions licensed by this license entry.
Name: licenseWebRTC
OID: .1.3.6.1.4.1.42303.2.4.2.1.22
Request Type: GET
Description: The amount of WebRTC instances licensed by this license entry.
