This chapter focuses on the LDAPConnection class in WMI, providing a table of properties related to LDAP connection configurations.

The LDAPConnection Class

The LdapConnection class provides information about LDAP connections. All properties are read only. For each configured LDAP connection, one class instance exists. The property Name has the key qualifier and uniquely identifies an LDAP instance.

LdapConnection Class Properties

The table below lists the properties of the ‘LdapConnection’ class in alphabetical order. All properties are read-only.

Some WMI queries are only available starting from anynode version 4.14.(Check out available WMI queries with the PowerShell command below).

To display all available contents of the System class locally without credentials, you can use the following command:

Get-WmiObject -Namespace "root\TESYSTEMS\anynode" -Class "System"

-Namespace "root\TESYSTEMS\anynode" : Specifies the WMI namespace for anynode.

-Class "LdapConnection" : Selects the "LdapConnection" class to retrieve its contents.

Property: CachedItemsCount

Type: uint32

Description: The property provides the number of items cached.

Property: EncryptionType

Type: uint32

Description: The property provides the used encryption type. Valid values are:

  • No encryption

  • SSL encryption

  • Start SSL encryption

Property: EstablishTime

Type: datetime

Description: The property provides the date and time when the LDAP connection was established. The format is the WMI datetime format.

Property: HostName

Type: string

Description: The property provides the host name or IP address of the LDAP server.

Property: HostPort

Type: uint32

Description: The property provides the port used for communication with the LDAP server.

Property: LastSearchTime

Type: datetime

Description: The property provides the date and time when the last search was done. The format is the WMI datetime format.

Property: Name

Type: string

Description: The property provides the name of the node. The name is unique, has the key attribute, and identifies a node instance.

Property: SearchCount

Type: uint32

Description: The property provides the number of searches done since the connection was established.

Property: Status

Type: uint32

Description: The property provides the status of the LDAP connection. Valid values are:

  • Idle

  • Connecting

  • Connected

  • ErrorConfiguration

  • ErrorAuthentication

  • ErrorServerDown

  • Error

Property: StatusErrorCode

Type: uint32

Description: The property provides the result code in case the Status is set to Error.
