The Routes Group
The following tables contain the OIDs and the corresponding names for the routes group. The table lists the valid actions
for the OIDs and the descriptions. The request type GET implies the support of the GETNEXT request.
Some SNMP queries are only available starting from anynode version 4.14.
Name: routeNumber
OID: .1.3.6.1.4.1.42303.2.3.1.0
Request Type: GET
Description: Contains the amount of entries in the following route table.
Name: routeTable
OID: .1.3.6.1.4.1.42303.2.3.2
Request Type: GET
Description: The table with information about the routes.
Name: routeEntry
OID: .1.3.6.1.4.1.42303.2.3.2.1
Request Type: GET
Description: The definition of the information for one route. The following OIDs in this table are available for each route. The at the end of the OID selects the route instance.
Name: routeIndex
OID: .1.3.6.1.4.1.42303.2.3.2.1.1
Request Type: GET
Description: The table index.
Name: routeName
OID: .1.3.6.1.4.1.42303.2.3.2.1.2
Request Type: GET
Description: Provides the symbolic name of the route. The data type is DisplayString.
Name: routeStatus
OID: .1.3.6.1.4.1.42303.2.3.2.1.3
Request Type: GET
Description: The state of this route instance. The data type is integer. Possible values are:
1: Disabled
2: Enabled
Name: routeActiveSessions
OID: .1.3.6.1.4.1.42303.2.3.2.1.4
Request Type: GET
Description: The amount of currently active sessions on this route.
Name: routeSuccessfulSessions
OID: .1.3.6.1.4.1.42303.2.3.2.1.5
Request Type: GET
Description: The amount of total successful sessions on this route since the last reset of the statistics.
Name: routeFailedSessions
OID: .1.3.6.1.4.1.42303.2.3.2.1.6
Request Type: GET
Description: The amount of total failed sessions (for any reason) on this route since the last reset of the statistics.
Name: routeFailedSessionsNoLicense
OID: .1.3.6.1.4.1.42303.2.3.2.1.7
Request Type: GET
Description: The amount of total failed sessions on this route with the reason "no license" since the last reset of the statistics.
Name: routeFailedSessionsNoAnswer
OID: .1.3.6.1.4.1.42303.2.3.2.1.8
Request Type: GET
Description: The amount of total failed sessions on all nodes with the reason "no answer" since the last reset of the statistics.
Name: routeFailedSessionsBusy
OID: .1.3.6.1.4.1.42303.2.3.2.1.9
Request Type: GET
Description: The amount of total failed sessions on this route with the reason "busy" since the last reset of the statistics.
Name: routeFailedSessionsMedia
OID: .1.3.6.1.4.1.42303.2.3.2.1.10
Request Type: GET
Description: The amount of total failed sessions on this route with the reason "media error" since the last reset of the statistics.
Name: routeCancelledSessions
OID: .1.3.6.1.4.1.42303.2.3.2.1.11
Request Type: GET
Description: The amount of total canceled sessions on this route since the last reset of the statistics. Canceled sessions means the incoming call was disconnected by the called party before the outgoing call could be established.
