The System Group

The System Group

The following list contains the OIDs and the corresponding names for the system group. The list shows the valid actions and descriptions for the OIDs. The request type GET implies the support of the GETNEXT request.

Keep in mind that the available call statistics (total successful and failed calls) are affected by the housekeeping process which can be configured in the monitor settings. If this feature is turned on, anynode stores the call history and automatically deletes the oldest records during the cleanup cycle when the maximum number of records, which is set to 500,000 per default, is reached.

Some SNMP queries are only available starting from anynode version 4.14.

Name: manufacturer

OID: .1.3.6.1.4.1.42303.2.1.1.0

Request Type: GET

Description: Provides the name of the manufacturer of this MIB. The data type is DisplayString.

Name: description

OID: .1.3.6.1.4.1.42303.2.1.2.0

Request Type: GET

Description: Provides the name of the product that this MIB is designed for. The data type is DisplayString.

Name: anynodeVersion

OID: .1.3.6.1.4.1.42303.2.1.3.0

Request Type: GET

Description: Provides the version number of the installed anynode software. The data type is DisplayString.

Name: anynodeMonitorVersion

OID: .1.3.6.1.4.1.42303.2.1.4.0

Request Type: GET

Description: Provides the version number of the installed anynode monitor software. The data type is DisplayString.

Name: anynodeState

OID: .1.3.6.1.4.1.42303.2.1.5.0

Request Type: GET

Description: Provides the information on whether the anynode service is running. The data type is an integer with the following possible values:

  • 0: unknown

  • 1: running

  • 2: stopped

Name: anynodeUpTime

OID: .1.3.6.1.4.1.42303.2.1.6.0

Request Type: GET

Description: The time (in hundredths of a second) since the anynode service was last re-initialized. The format is TimeTicks.

Name: licenseState

OID: .1.3.6.1.4.1.42303.2.1.7.0

Request Type: GET

Description: The overall state of the installed licenses. The data type is an integer with the following possible values:

  • 0: none

  • 1: demo

  • 2: valid

  • 3: expires

  • 4: expiresWarning

  • 5: expiredCritical

  • 6: expired

  • 7: expiredAll

  • 8: expiredAllUsingDemo

  • 9: invalid

  • 10: invalidAll

  • 11: invalidAllUsingDemo

Name: certificateState

OID: .1.3.6.1.4.1.42303.2.1.8.0

Request Type: GET

Description: The overall state of the installed certificates. The data type is an integer with the following possible values:

  • 0: none

  • 1: notYetValid

  • 2: valid

  • 3: expiresWarning

  • 4: expiresCritical

  • 5: expired

  • 6: expiredAll

Name: networkState

OID: .1.3.6.1.4.1.42303.2.1.9.0

Request Type: GET

Description: Provides the information if the network connection for all nodes is available. The data type is an integer with the following possible values:

  • 1: ok

  • 2: error

If an error is indicated, refer to the details for each node to get more information.

Name: registrationState

OID: .1.3.6.1.4.1.42303.2.1.10.0

Request Type: GET

Description: Provides the information if the registrations for all nodes are successful. The data type is an integer with the following possible values:

  • 1: ok

  • 2: error

If an error is indicated, refer to the details for each node to get more information.

Name: nodeCount

OID: .1.3.6.1.4.1.42303.2.1.11.0

Request Type: GET

Description: Provides the number of available nodes.

Name: routeCount

OID: .1.3.6.1.4.1.42303.2.1.12.0

Request Type: GET

Description: Provides the number of available routes.

Name: operatingSystem

OID: .1.3.6.1.4.1.42303.2.1.13.0

Request Type: GET

Description: Provides the name of the operating system the anynode service is running on. The data type is DisplayString.

Name: operatingSystemVersion

OID: .1.3.6.1.4.1.42303.2.1.14.0

Request Type: GET

Description: Provides the version of the operating system the anynode service is running on. The data type is DisplayString.

Name: totalLicensedSessions

OID: .1.3.6.1.4.1.42303.2.1.15.0

Request Type: GET

Description: The amount of sessions licensed by all installed licenses.

Name: totalActiveSessions

OID: .1.3.6.1.4.1.42303.2.1.16.0

Request Type: GET

Description: The amount of currently active sessions on all nodes.

Name: totalSuccessfulSessions

OID: .1.3.6.1.4.1.42303.2.1.17.0

Request Type: GET

Description: The amount of total successful sessions on all nodes since the last reset of statistics.

Name: totalFailedSessions

OID: .1.3.6.1.4.1.42303.2.1.18.0

Request Type: GET

Description: The amount of total failed sessions (for any reason) on all nodes since the last reset of statistics.

Name: totalFailedSessionsNoLicense

OID: .1.3.6.1.4.1.42303.2.1.19.0

Request Type: GET

Description: The amount of total failed sessions on all nodes with reason no license since the last reset of statistics.

Name: totalFailedSessionsNoRoute

OID: .1.3.6.1.4.1.42303.2.1.20.0

Request Type: GET

Description: The amount of failed sessions on all nodes with reason no route since the last reset of statistics.

Name: totalFailedSessionsNoAnswer

OID: .1.3.6.1.4.1.42303.2.1.21.0

Request Type: GET

Description: The amount of failed sessions on all nodes with reason no answer since the last reset of statistics.

Name: totalFailedSessionsBusy

OID: .1.3.6.1.4.1.42303.2.1.22.0

Request Type: GET

Description: The amount of failed sessions on all nodes with reason busy since the last reset of statistics.

Name: totalFailedSessionsMedia

OID: .1.3.6.1.4.1.42303.2.1.23.0

Request Type: GET

Description: The amount of failed sessions on all nodes with reason media error since the last reset of the statistics.

Name: totalCancelledSessions

OID: .1.3.6.1.4.1.42303.2.1.24.0

Request Type: GET

Description: The amount of canceled sessions on all nodes since the last reset of the statistics. Canceled sessions mean the incoming call was disconnected by the caller before the outgoing call could be established.

Name: statisticUpTime

OID: .1.3.6.1.4.1.42303.2.1.25.0

Request Type: GET

Description: The time (in hundredths of a second) since the last reset of the statistics, which implies the reset of the call history. The format is TimeTicks.

Name: totalLicensedG722Decoder

OID: .1.3.6.1.4.1.42303.2.1.26.0

Request Type: GET

Description: The amount of G.722 decoder instances licensed by all active licenses.

Name: totalLicensedG722Encoder

OID: .1.3.6.1.4.1.42303.2.1.27.0

Request Type: GET

Description: The amount of G.722 encoder instances licensed by all active licenses.

Name: totalLicensedG729Decoder

OID: .1.3.6.1.4.1.42303.2.1.28.0

Request Type: GET

Description: The amount of G.729 decoder instances licensed by all active licenses.

Name: totalLicensedG729Encoder

OID: .1.3.6.1.4.1.42303.2.1.29.0

Request Type: GET

Description: The amount of G.729 encoder instances licensed by all active licenses.

Name: totalLicensedOpusDecoder

OID: .1.3.6.1.4.1.42303.2.1.30.0

Request Type: GET

Description: The amount of OPUS decoder instances licensed by all active licenses.

Name: totalLicensedOpusEncoder

OID: .1.3.6.1.4.1.42303.2.1.31.0

Request Type: GET

Description: The amount of OPUS encoder instances licensed by all active licenses.

Name: totalUsedSessions

OID: .1.3.6.1.4.1.42303.2.1.32.0

Request Type: GET

Description: The amount of currently used session licenses.

Name: totalUsedG722Decoder

OID: .1.3.6.1.4.1.42303.2.1.33.0

Request Type: GET

Description: The amount of currently used G.722 decoder licenses.

Name: totalUsedG722Encoder

OID: .1.3.6.1.4.1.42303.2.1.34.0

Request Type: GET

Description: The amount of currently used G.722 encoder licenses.

Name: totalUsedG729Decoder

OID: .1.3.6.1.4.1.42303.2.1.35.0

Request Type: GET

Description: The amount of currently used G.729 decoder licenses.

Name: totalUsedG729Encoder

OID: .1.3.6.1.4.1.42303.2.1.36.0

Request Type: GET

Description: The amount of currently used G.729 encoder licenses.

Name: totalUsedOpusDecoder

OID: .1.3.6.1.4.1.42303.2.1.37.0

Request Type: GET

Description: The amount of currently used OPUS decoder licenses.

Name: totalUsedOpusEncoder

OID: .1.3.6.1.4.1.42303.2.1.38.0

Request Type: GET

Description: The amount of currently used OPUS encoder licenses.

Name: statisticsRemovedSessions

OID: .1.3.6.1.4.1.42303.2.1.39.0

Request Type: GET

Description: The amount of sessions that have been removed from the call history in the last interval because the configured limits were reached.

Name: totalLicensedRecording

OID: .1.3.6.1.4.1.42303.2.1.40.0

Request Type: GET

Description: The amount of Recording sessions licensed by all active licenses.

Name: totalUsedRecording

OID: .1.3.6.1.4.1.42303.2.1.41.0

Request Type: GET

Description: The amount of currently used Recording session licenses.

Name: totalLicensedwebrtcClient

OID: .1.3.6.1.4.1.42303.2.1.42.0

Request Type: GET

Description: The amount of WebRTC instances licensed by all active licenses.

Name: totalUsedwebrtcClient

OID: .1.3.6.1.4.1.42303.2.1.43.0

Request Type: GET

Description: The amount of currently used WebRTC licenses.

Name: anynodeSystemIdentifier

OID: .1.3.6.1.4.1.42303.2.1.44.0

Request Type: GET

Description: Provides the System Identifier of the anynode instance. The data type is DisplayString.

Name: anynodeSystemName

OID: .1.3.6.1.4.1.42303.2.1.45.0

Request Type: GET

Description: Provides the System Name of the anynode instance. The data type is DisplayString.

Name: maintenanceModeState

OID: .1.3.6.1.4.1.42303.2.1.46.0

Request Type: GET

Description: Provides information if the anynode maintenance Mode is active. The data type is an integer, possible values are:

  • 1: off

  • 2: on

Name: tracingState

OID: .1.3.6.1.4.1.42303.2.1.47.0

Request Type: GET

Description: Provides the information if the anynode trace is collecting trace log information. The data type is an integer, possible values are:

  • 0: off

  • 1: on

Name: anynodeFrontendVersion

OID: .1.3.6.1.4.1.42303.2.1.48.0

Request Type: GET

Description: Provides the version number of the installed anynode frontend software. The data type is DisplayString.

Name: anynodeOpenSSLVersion

OID: .1.3.6.1.4.1.42303.2.1.49.0

Request Type: GET

Description: Provides the version number of the installed OpenSSL library. The data type is DisplayString.

Name: systemCpu

OID: .1.3.6.1.4.1.42303.2.1.50.0

Request Type: GET

Description: Returns the CPU utilization of the system's resources provided by anynode.

Name: systemRam

OID: .1.3.6.1.4.1.42303.2.1.51.0

Request Type: GET

Description: Returns the Memory utilization of the system's resources provided by anynode.

Name: systemDisk

OID: .1.3.6.1.4.1.42303.2.1.52.0

Request Type: GET

Description: Returns the Disk utilization of the system's resources provided by anynode on the storage where it is installed.

Name: mediaRecordingState

OID: .1.3.6.1.4.1.42303.2.1.53.0

Request Type: GET

Description: Provides information if the anynode Media Recording Mode is active. The data type is an integer, possible values are:

  • 1: off

  • 2: on
