Monitoring

The eventObjects Group

The following tables contain the OIDs and the corresponding name for the eventObject group. The OIDs are used with the Trap eventNotification. There is no operation to read these OIDs. There is no operation to read these OIDs. For information about the available events and the parameters signalled by the event, refer to the technical notes containing the event descriptions.

Name: eventObjectDateTime

OID: .1.3.6.1.4.1.42303.2.11.1.0

Request Type: GET

Description: The date and time in ISO 8601 format when the event was generated. The data type is DisplayString.

Name: eventObjectMessageText

OID: .1.3.6.1.4.1.42303.2.11.2.0

Request Type: GET

Description: The message text as written to the event log. The data type is DisplayString.

Name: eventObjectSeverity

OID: .1.3.6.1.4.1.42303.2.11.3.0

Request Type: GET

Description: The severity of the event. The data type is integer, with the following values:

• 0: Error

• 1: Warning

• 2: Informational

Name: eventObjectId

OID: .1.3.6.1.4.1.42303.2.11.4.0

Request Type: GET

Description: The event identifier. The data type is integer.

Name: eventObjectSystemName

OID: .1.3.6.1.4.1.42303.2.11.5.0

Request Type: GET

Description: The name of the machine on which anynode is running. The data type is DisplayString.

Name: eventObjectSystemId

OID: .1.3.6.1.4.1.42303.2.11.6.0

Request Type: GET

Description: The unique system identifier created when anynode was installed for the first time. The data type is DisplayString.

Name: eventObjectVersion

OID: .1.3.6.1.4.1.42303.2.11.7.0

Request Type: GET

Description: The version of the anynode software. The data type is DisplayString.

Name: eventObjectFrontendLink

OID: .1.3.6.1.4.1.42303.2.11.8.0

Request Type: GET

Description: The link to launch the anynode frontend, specified in the anynode Monitor event transport configuration. The data type is DisplayString.

Name: eventObjectMessageParam1

OID: .1.3.6.1.4.1.42303.2.11.9.0

Request Type: GET

Description: The first event-specific parameter. Optional and only available if the event contains one or more parameters. The data type is DisplayString.

Name: eventObjectMessageParam2

OID: .1.3.6.1.4.1.42303.2.11.10.0

Request Type: GET

Description: The second event-specific parameter. Optional and only available if the event contains two or more parameters. The data type is DisplayString.

Name: eventObjectMessageParam3

OID: .1.3.6.1.4.1.42303.2.11.11.0

Request Type: GET

Description: The third event-specific parameter. Optional and only available if the event contains three or more parameters. The data type is DisplayString.

Name: eventObjectMessageParam4

OID: .1.3.6.1.4.1.42303.2.11.12.0

Request Type: GET

Description: The fourth event-specific parameter. Optional and only available if the event contains four parameters. The data type is DisplayString.
