OpenScape 4000 Node Details
This chapter gives an orientation about the Mitel OpenScape node objects in anynode as follows. The node object details displayed are derived from the entries configured via the anynode wizard, and the template defaults applied to the Mitel OpenScape 4000 in this configuration example as shown in Guided Scenario Setup.
-
Node: Handles session limits, tone announcements, and STIR/SHAKEN identity verification.
-
SIP Node: Manages SIP trunk settings including domain mapping, transport connections, and call routing.
-
SIP User Agent: Implements SIP protocol features based on RFC standards for registration, media, and identity.
-
Media Negotiation: Configures media transport, codec settings, and security levels for audio communication.
-
SIP Transport: Defines SIP protocol behavior, transport types, and port configurations.
-
Network Peer Whitelist: Specifies trusted IP peers and integrates with SIP and media settings.
-
Network Controller: Controls IP bindings, DNS, and port ranges for network-level communication.
-
Network Security Profile: Manages certificates, trusted peers, and TLS/DTLS encryption settings.
Within the configuration dialogs of the anynode frontend, hovering the mouse pointer over the icon displays a tooltip with additional details about the corresponding settings if the icon is available. Likewise, clicking the icon in the header of a configuration section expands the section to show further configuration options if the icon is present.
